LCT (B473)
SM 1-23 B064 Series/B140 Series/G126
Installation
1.4.2 INSTALLATION PROCEDURE
Removing Tape
1. Remove the filament tape from the body [A] and top cover [B] of the LCT.
2. Remove the tape under the lid [C] of the LCT.
B473I002.WMF
B473I001.WMF
[C]
[A]
[B]
