Ricoh Aficio 2075 SP User Manual

REPLACEMENT AND ADJUSTMENT
B706 16 SM
3.5.6 STAPLE WASTE HOPPER SENSOR
1. Open the front door, pull out the stapler unit, then remove the rear cover.
2. Remove the rear cover ( x 2).
3. Remove the staple waste hopper [A] ( x 1).
4. Remove the hopper holder [B] ( x 2).
5. Replace the staple waste hopper sensor [C] ( x 1).
B706R517.WMF
[B]
[A]
[C]
