ADF (B140 SERIES/B064 SERIES)
SM 3-135 B064 Series/B140 Series/G126
Replacement
Adjustment
3.13.8 ORIGINAL LENGTH SENSORS
[A]: Open the original tray.
[B]: Lower cover ( x 4)
[C]: Original length sensor 1 – B5 ( x 1)
[D]: Original length sensor 2 – A4 ( x 1)
[E]: Original length sensor 3 – LG ( x 1)
B140R876.WMF
[A]
[B]
[C]
[D]
[E]
