REPLACEMENT AND ADJUSTMENT
SM 23 B706
3000-Sheet
Finisher
B706
3.8 Z-FOLD JOGGER UNIT
3.8.1 Z-FOLD JOGGER UNIT COVER
1. Open the front door.
2. Pull out the stapler tray unit [A].
3. Remove the Z-fold jogger unit cover [B] ( x 2).
B706R101.WMF
[A]
[B]
