FUSING UNIT
B064/B140 Series/G126 3-68 SM
3.9.7 PRESSURE ROLLER CLEANING UNIT
B064 Series
Fusing unit ( 3.9.1)
[A]: Lower cover ( x 1)
[B]: Cleaning roller bracket ( x 2)
[C]: Cleaning roller ( x 1)
NOTE:
1) When attaching the lower cover of the pressure roller cleaning roller,
make sure that the tab [D] engages with the groove [E].
2) If the bushings are noisy after replacement, lubricate them on both ends
and the holes where the bushings are attached with Barietta Grease
L553R.
B140R990.WMF
[A]
[B]
[C]
[D]
[E]
