ADF (B140 SERIES/B064 SERIES)
B064/B140 Series/G126
3-140
SM
3.13.14
PICK-UP ROLLER MOTOR AND HP SENSOR
Open the feed cover.
ADF Rear cover (
3.13.1)
[A]:
Pick-up roller lift motor (
x 2,
x 1)
[B]:
Pick-up roller HP sensor (
x 1)
B140R883.W
MF
[A]
[B]
313
315
