FUSING UNIT
B064/B140 Series/G126 3-78 SM
3.9.10 STRIPPER PAWLS
B064 Series
Remove the fusing unit ( 3.9.1)
[A]: Top cover ( x 1)
[B]: Bracket ( x 1, spring x 1)
[C]: Inner cover ( x 2)
[D]: Stripper pawl ( x 1, spring x 3)
B140R801.WMF
B140R800.WMF
[C]
[D]
[A]
[B]
