DUPLEX UNIT
B064/B140 Series/G126 3-90 SM
3.10.7 DUPLEX TRANSPORT SENSOR 3
[A]: Right half of table ( x 2,  x 1)
• The front screw is a shoulder screw. Insert the screws in the correct holes
when re-attaching.
[B]: Remove the screw in the center of the table to release the sensor bracket
below.
[C]: Transport sensor 3 ( x 1)
B140R816.WMF
[A]
[B]
[C]
