6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-198 2461-901-01 A/November 2015
:TRIGger:BLOCk:CONFig:RECall
This command recalls the system settings that are stored in a source or measure configuration list.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings
Not applicable
Usage
:TRIGger:BLOCk:CONFig:RECall <blockNumber>, "<configurationList>"
:TRIGger:BLOCk:CONFig:RECall <blockNumber>, "<configurationList>", <index>
:TRIGger:BLOCk:CONFig:RECall <blockNumber>, "<configurationList>", <index>,
"<configurationList2>", <index2>
<blockNumber>
The sequence of the block in the trigger model
<configurationList>
A string that defines the configuration list to recall
<index>
The index in the configuration list to recall; defaults to 1 if not selected
<configurationList2>
The second source or measure configuration list from which to recall
settings; the type must be opposite of
<configurationList>
<index2>
The index in the second configuration list to recall; defaults to 1 if not
selected
Details
When the trigger model reaches a configuration recall block, the settings in the specified configuration
list are recalled if a single configuration list is specified. If both measure and source configuration lists
are specified, measure and source settings are recalled from the next index in each list when this
block is reached. The index numbers recalled may not match; it depends on the number of indexes in
each list and what index number each list is on.
You can restore a specific set of configuration settings in the configuration list by defining the index.
Example
SOUR:CONF:LIST:CRE "biasLevel"
SOUR:FUNC VOLT
SENS:FUNC "CURR"
SOUR:VOLT:LEV 5
SOUR:CONF:LIST:STORE "biasLevel"
TRIG:BLOCK:CONF:RECALL 1, "biasLevel", 1
Create a configuration list named
biasLevel. Set the source function to 5 V
and the measure function to current.
Store the source settings at index 1 in the
configuration list named biasLevel.
Recall index 1 of the configuration list
named biasLevel as block 1 of the trigger
model.
Also see
Configuration lists (on page 3-30)
[:SENSe[1]]:CONFiguration:LIST:STORe (on page 6-78)
:SOURce[1]:CONFiguration:LIST:STORe (on page 6-88)
