6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-60 2461-901-01 A/November 2015
[:SENSe[1]]:<function>:NPLCycles
This command sets the time that the input signal is measured for the selected function.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
1
Usage
[:SENSe[1]]:<function>:NPLCycles <n>
[:SENSe[1]]:<function>:NPLCycles DEFault
[:SENSe[1]]:<function>:NPLCycles MINimum
[:SENSe[1]]:<function>:NPLCycles MAXimum
[:SENSe[1]]:<function>:NPLCycles?
[:SENSe[1]]:<function>:NPLCycles? DEFault
[:SENSe[1]]:<function>:NPLCycles? MINimum
[:SENSe[1]]:<function>:NPLCycles? MAXimum
<function>
The measure function:
• Current: CURRent[:DC]
• Resistance: RESistance
• Voltage:
VOLTage[:DC]
<n>
The number of power-line cycles for each measurement: 0.01 to 10
Details
This command sets the amount of time that the input signal is measured.
The amount of time is specified as the number of power line cycles (NPLCs). Each PLC for 60 Hz is
16.67 ms (1/60) and each PLC for 50 Hz is 20 ms (1/50). For 60 Hz, if you set the NPLC to 0.1, the
measure time is 1.667 ms.
This command is set for the measurement of specific functions (current, resistance, or voltage).
The shortest amount of time results in the fastest reading rate, but increases the reading noise and
decreases the number of usable digits.
The longest amount of time provides the lowest reading noise and more usable digits, but has the
slowest reading rate.
Settings between the fastest and slowest number of PLCs are a compromise between speed and
noise.
If you change the PLCs, you may want to adjust the displayed digits to reflect the change in usable
digits.
If you send this command without the <function> parameter, it sets the NPLCs for all functions.
