Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-311
trigger.tsplinkin[N].edge
This attribute indicates which trigger edge controls the trigger event detector for a trigger line.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
TSP-Link line N reset
Configuration script
trigger.EDGE_FALLING
Usage
detectedEdge = trigger.tsplinkin[N].edge
trigger.tsplinkin[N].edge = detectedEdge
detectedEdge
The trigger mode:
• Detect falling-edge triggers as inputs: trigger.EDGE_FALLING
• Detect rising-edge triggers as inputs: trigger.EDGE_RISING
•
Detect either falling or rising-edge triggers as inputs: trigger.EDGE_EITHER
N
The trigger line (1 to 3)
Details
When the edge is detected, the instrument asserts a TTL-low pulse for the output.
The output state of the I/O line is controlled by the trigger logic. The user-specified output state of the
line is ignored.
Example
tsplink.line[3].mode = tsplink.MODE_TRIGGER_OPEN_DRAIN
trigger.tsplinkin[3].edge = trigger.EDGE_RISING
Sets synchronization line 3 to
detect rising edge triggers as input.
Also see
digio.writeport() (on page 8-54)
tsplink.line[N].mode (on page 8-319)
tsplink.line[N].reset() (on page 8-320)
trigger.tsplinkin[N].overrun
This attribute indicates if the event detector ignored an event while in the detected state.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (R) Yes
Instrument reset
Recall setup
TSP-Link line N clear
Not applicable Not applicable
Usage
overrun = trigger.tsplinkin[N].overrun
overrun
Trigger overrun state
N
The trigger line (1 to 3)
