Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2461-901-01 A/November 2015 8-303
trigger.timer[N].delay
This attribute sets and reads the timer delay.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Trigger timer N reset
Configuration script
10e-6 (10 µs)
Usage
interval = trigger.timer[N].delay
trigger.timer[N].delay = interval
interval
Delay interval in seconds (8 µs to 100 ks)
N
Trigger timer number (1 to 4)
Details
Once the timer is enabled, each time the timer is triggered, it uses this delay period.
Assigning a value to this attribute is equivalent to:
trigger.timer[N].delaylist = {interval}
This creates a delay list of one value.
Reading this attribute returns the delay interval that will be used the next time the timer is triggered.
If you use the trigger timer with a trigger model, make sure the trigger timer delay is set so that the
readings are paced correctly.
Example
trigger.timer[1].delay = 50e-6
Set the trigger timer 1 to delay for
50 µs.
Also see
trigger.timer[N].reset() (on page 8-305)
trigger.timer[N].delaylist
This attribute sets an array of timer intervals.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Trigger timer N reset
Configuration script
{10e-6}
Usage
intervals = trigger.timer[N].delaylist
trigger.timer[N].delaylist = intervals
intervals
Table of delay intervals in seconds
N
Trigger timer number (1 to 4)
