Keithley 2461 Reference Manual

Section
8: TSP command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
8-248 2461-901-01 A/November 2015
Trigger events
Event description Event constant
No trigger event
trigger.EVENT_NONE
Trigger event blender N (1 to 2), which combines trigger
events
trigger.EVENT_BLENDERN
Trigger timer N (1 to 4) expired
trigger.EVENT_TIMERN
Source limit condition occurs
trigger.EVENT_SOURCE_LIMIT
Example
digio.line[2].mode = digio.MODE_TRIGGER_OUT
trigger.digout[2].stimulus = trigger.EVENT_TIMER3
Set the stimulus for output digital
trigger line 2 to be the expiration of
trigger timer 3.
Also see
digio.line[N].mode (on page 8-50)
digio.line[N].reset() (on page 8-52)
Digital I/O port configuration (on page 3-87)
trigger.digin[N].clear() (on page 8-241)
trigger.digout[N].assert() (on page 8-244)
trigger.lanin[N].clear()
This function clears the event detector for a LAN trigger.
Type TSP-Link accessible
Affected by Where saved Default value
Function Yes
Usage
trigger.lanin[N].clear()
N
The LAN event number (1 to 8) to clear
Details
The trigger event detector enters the detected state when an event is detected. This function clears a
trigger event detector and discards the previous of the trigger packet.
This function clears all overruns associated with this LAN trigger.
Example
trigger.lanin[5].clear()
Clears the event detector with LAN event trigger 5.
Also see
trigger.lanin[N].overrun (on page 8-249)
