6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-220 2461-901-01 A/November 2015
:TRIGger:LAN<n>:OUT:PROTocol
This command sets the LAN protocol to use for sending trigger messages.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings TCP
Usage
:TRIGger:LAN<n>:OUT:PROTocol
:TRIGger:LAN<n>:OUT:PROTocol?
<n>
The LAN event number (1 to 8)
<protocol>
The protocol to use for messages from the trigger:
• TCP
• UDP
•
MULTicast
Details
The LAN trigger listens for trigger messages on all the supported protocols. However, it uses the
designated protocol for sending outgoing messages.
After you change this setting, you must re-connect the LAN trigger event generator before you can
send outgoing event messages.
When multicast is selected, the trigger IP address is ignored and event messages are sent to the
multicast address 224.0.23.159.
Example
:TRIG:LAN1:OUT:PROT TCP
:TRIG:LAN1:OUT:CONN:STAT
Set the LAN protocol for trigger messages to be
TCP and re-connect the LAN trigger event
generator.
Also see
:TRIGger:LAN<n>:OUT:CONNect:STATe (on page 6-218)
:TRIGger:LAN<n>:OUT:IP:ADDRess (on page 6-218)
:TRIGger:LAN<n>:OUT:STIMulus
This command specifies events that cause this trigger to assert.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings NONE
Usage
:TRIGger:LAN<n>:OUT:STIMulus <LANevent>
:TRIGger:LAN<n>:OUT:STIMulus?
<n>
A number specifying the trigger packet over the LAN for which to set or query the
trigger source (1 to 8)
<LANevent>
The LAN event that causes this trigger to assert
