Keithley 2461 Reference Manual

Section
6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument
Reference Manual
6-216 2461-901-01 A/November 2015
:TRIGger:LAN<n>:IN:CLEar
This command clears the event detector for a LAN trigger.
Type Affected by Where saved Default value
Command only
Not applicable
Not applicable
Not applicable
Usage
:TRIGger:LAN<n>:IN:CLEar
<n>
The LAN event number (1 to 8) to clear
Details
The trigger event detector enters the detected state when an event is detected. This function clears a
trigger event detector and discards the previous of the trigger packet.
This function clears all overruns associated with this LAN trigger.
Example
:TRIG:LAN5:IN:CLE
Clears the event detector with LAN packet 5.
Also see
:TRIGger:LAN<n>:IN:OVERrun? (on page 6-217)
:TRIGger:LAN<n>:IN:EDGE
This command sets the trigger operation and detection mode of the specified LAN event.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings EITH
Usage
:TRIGger:LAN<n>:IN:EDGE <mode>
:TRIGger:LAN<n>:IN:EDGE?
<n>
The LAN event number (1 to 8)
<mode>
The trigger mode; see the Details for more information
Details
This command controls how the trigger event detector and the output trigger generator operate on the
given trigger. These settings are intended to provide behavior similar to the digital I/O triggers.
LAN trigger mode values
Mode Trigger packets detected as input LAN trigger packet generated for
output with a…
EITHer
Rising or falling edge (positive or negative state) negative state
FALLing
Falling edge (negative state)
negative state
RISing
Rising edge (positive state)
positive state
