Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 6:
SCPI command reference
2461-901-01 A/November 2015 6-71
[:SENSe[1]]:<function>:SRATe
This command defines the precise acquisition rate at which the digitizing measurements are made.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
100,000
Usage
[:SENSe[1]]:<function>:SRATe <n>
[:SENSe[1]]:<function>:SRATe?
[:SENSe[1]]:<function>:SRATe? DEFault
[:SENSe[1]]:<function>:SRATe? MINimum
[:SENSe[1]]:<function>:SRATe? MAXimum
<function>
The digitize function:
• Digitize current: DIGitize:CURRent
•
Digitize voltage: DIGitize:VOLTage
<n>
1,000 to 1,000,000 readings per second
Details
The sample rate determines how fast the Model 2461 acquires a digitized reading.
Set the sample rate before setting the aperture. If the aperture setting is too high for the selected
sample rate, it is automatically adjusted to the highest aperture that can be used with the sample rate.
Example
DIG:FUNC "CURR"
DIG:CURR:SRATE 1000000
DIG:CURR:APER AUTO
DIG:COUN 10
MEAS:DIG?
Set the digitize function to measure current.
Set the sample rate to 1,000,000, with a
count of 10, and automatic aperture.
Make a digitize measurement.
Also see
[:SENSe[1]]:<function>:APERture (on page 6-52)
