Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 6:
SCPI command reference
2461-901-01 A/November 2015 6-59
[:SENSe[1]]:<function>:DELay:USER<n>
This command sets a user-defined delay that you can use in the trigger model.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Function change
Save settings
Measure configuration list
0
Usage
[:SENSe[1]]:<function>:DELay:USER<n> <delayTime>
[:SENSe[1]]:<function>:DELay:USER<n> DEFault
[:SENSe[1]]:<function>:DELay:USER<n> MINimum
[:SENSe[1]]:<function>:DELay:USER<n> MAXimum
[:SENSe[1]]:<function>:DELay:USER<n>?
[:SENSe[1]]:<function>:DELay:USER<n>? DEFault
[:SENSe[1]]:<function>:DELay:USER<n>? MINimum
[:SENSe[1]]:<function>:DELay:USER<n>? MAXimum
<function>
The measure function:
• Current: CURRent[:DC]
• Resistance: RESistance
• Voltage: VOLTage[:DC]
The digitize function:
• Digitize current: DIGitize:CURRent
• Digitize voltage:
DIGitize:VOLTage
<n>
The user delay to which this time applies (1 to 5)
<delayTime>
The delay (0 for no delay, or 167 ns to 10 ks)
Details
To use this command in a trigger model, assign the delay to the dynamic delay block using the
corresponding MEAS1 to MEAS5 parameter that matches the delay number specified here (see the
Example below).
The delay is specific to the selected function.
Example
:CURRent:DELay:USER1 .2
:TRIGger:BLOCk:DELay:DYNamic 6, MEAS1
Set user delay 1 to 0.2 s for current
measurements. Set trigger block 6 to be a
dynamic delay that is set to user delay 1 for the
function being measured.
Also see
:TRIGger:BLOCk:DELay:DYNamic (on page 6-200)
