8: TSP command reference Model 2461 Interactive SourceMeter® Instrument
8-286 2461-901-01 A/November 2015
Example 3
trigger.model.setblock(7, trigger.BLOCK_CONFIG_PREV, "measTrigList",
"sourTrigList")
Configure trigger block 7 to load the previous index in both the configuration list named measTrigList and
the configuration list named
.
Also see
Configuration lists (on page 3-30)
trigger.model.setblock() — trigger.BLOCK_CONFIG_RECALL
This function recalls the system settings that are stored in a source or measure configuration list, or both a source
and measure configuration list.
Type TSP-Link accessible Affected by Where saved Default value
Instrument reset
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_CONFIG_RECALL, configurationList)
trigger.model.setblock(blockNumber, trigger.BLOCK_CONFIG_RECALL, configurationList,
index)
trigger.model.setblock(blockNumber, trigger.BLOCK_CONFIG_RECALL, configurationList,
index, optionalConfigList)
trigger.model.setblock(blockNumber, trigger.BLOCK_CONFIG_RECALL, configurationList,
index, optionalConfigList, optionalIndex)
The sequence of the block in the trigger model
A string that defines the source or measure configuration list to
recall
The index in the configuration list to recall; default is 1
A string that defines the second configuration list to recall the
index from; must be the opposite type of list than the first; for
example, if the first configuration list is a measure list, the
second configuration list must be a source list
The index to recall from the second configuration list; defaults to
1
Details
If two configuration lists are specified with this command, they must not be of the same type. For
example, if the first configuration list is a measure configuration list, the second configuration list must
be a source configuration list. The order of the configuration lists does not matter with this command,
as long as they are of the opposite type.
