Keithley 2461 Reference Manual

Section
7: Introduction to TSP operation Model 2461 Interactive SourceMeter® Instrument
Reference Manual
7-36 2461-901-01 A/November 2015
Creating a run configuration
A run configuration allows you to download multiple script files to an instrument and execute them as
a single script.
To create a run configuration:
1. On the Run menu, select Run Configurations. The Run Configurations dialog box opens.
2. The left pane of the dialog box lists existing run and debug configurations. Select the script where
the Run Configuration will be saved.
3. Click the New launch configuration icon
at the top left of the dialog box. By default, a new
configuration is created with the name New_configuration.
Figure 167: Run Configurations dialog box
