Interactive SourceMeter® Instrument Reference Manual Section 2:
2461-901-01 A/November 2015 2-21
STATISTICS swipe screen
The STATISTICS swipe screen contains information about the readings in the active reading buffer.
When the reading buffer is configured to fill continuously and overwrite old data with new data, the
buffer statistics include the data that was overwritten. To get statistics that do not include data that
has been overwritten, define a large buffer size that will accommodate the number of readings you
will make. You can use the Clear Active Buffer button on this screen to clear the data from the
active reading buffer.
Figure 20: Model 2461 STATISTICS swipe screen
USER swipe screen
You can program custom text that appears on the USER swipe screen. For example, you can
program the Model 2461 to show that a test is in process. Refer to the Model 2461 Reference
Manual, "Customizing a message for the USER swipe screen"
Figure 21: USER swipe screen
Menu overview
To access the main menu, press the MENU key on the Model 2461 front panel. The figure below
shows the organization of the main menu.
Figure 22: Model 2461 main menu
