:SOURce[1]:<function>:PROTection[:LEVel]:TRIPped?
This command indicates if the overvoltage source protection feature is active.
Type Affected by Where saved Default value
Query only Not applicable Not applicable Not applicable
Usage
:SOURce[1]:VOLTage:PROTection[:LEVel]:TRIPped?
Details
When overvoltage protection is active, the instrument restricts the maximum voltage level that the
instrument can source.
If the voltage source does not exceed the set limits, the return is 0. If the voltage source exceeds the
set limits, the return is 1.
Example
SOUR:VOLT:PROT:TRIP?
If overvoltage protection is active, the output is:
1
Also see
Overvoltage protection (on page 2-121)
:SOURce[1]:<function>:PROTection[:LEVel] (on page 6-96)
:SOURce[1]:<function>:RANGe
This command selects the range for the source for the selected source function.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Source configuration list
Save settings
Source configuration list
Current: 1 µA
Voltage: 200 mV
Usage
:SOURce[1]:<function>:RANGe <n>
:SOURce[1]:<function>:RANGe?
:SOURce[1]:<function>:RANGe? DEFault
:SOURce[1]:<function>:RANGe? MINimum
:SOURce[1]:<function>:RANGe? MAXimum
<function>
The source function to which this setting applies:
• Current: CURRent
• Voltage: VOLTage
<n>
Set to the maximum expected voltage or current to be sourced; see
Details for values; the ranges are:
• Current: -10 A to 10 A
•
Voltage: -100 V to 100 V
