Section

6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument

Reference Manual

6-206 2461-901-01 A/November 2015

:TRIGger:BLOCk:NOTify

This command defines a trigger model block that generates a trigger event and immediately continues to the next

block.

Type Affected by Where saved Default value

Command only

Recall settings

Instrument reset

Power cycle

Save settings

Not applicable

Usage

:TRIGger:BLOCk:NOTify <blockNumber>, <notifyID>

The sequence of the block in the trigger model

The identification number of the notification; 1 to 8

Details

When trigger model execution reaches a notify block, the instrument generates a trigger event and

immediately continues to the next block.

Other commands can reference the event that the notify block generates. This assigns a stimulus

somewhere else in the system. For example, you can use the notify event as the stimulus of a

hardware trigger line, such as a digital I/O line.

When you call this event, you use the format NOTIFY followed by the notify identification number. For

example, if you assign <notifyID> as 4, you would refer to it as NOTIFY4 in the command that

references it.

Example

:TRIG:BLOC:NOT 5, 2

:TRIG:BLOC:BRAN:EVEN 6, NOTIFY2, 2

Define trigger model block 5 to be the notify 2

event. Assign the notify 2 event to be the trigger

for stimulus for the branch event for block 6.

Also see

Notify block (on page 3-112)
