Keithley 2461 Reference Manual

Model 2461
Interactive SourceMeter® Instrument Reference Manual Section 6:
SCPI command reference
2461-901-01 A/November 2015 6-183
Details
This command sets the blender event detector to the undetected state and resets the overrun
indicator of the event detector.
Example
:TRIG:BLEN2:CLE
Clears the event detector for blender 2.
Also see
None
:TRIGger:BLENder<n>:MODE
This command selects whether the blender performs OR operations or AND operations.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Trigger blender clear
Save settings
AND
Usage
:TRIGger:BLENder<n>:MODE <operation>
:TRIGger:BLENder<n>:MODE?
<n>
The blender number (1 or 2)
<operation>
The type of operation:
• OR
•
AND
Details
This command selects whether the blender waits for any one event (OR) or waits for all selected
events (AND) before signaling an output event.
Example 1
:DIG:LINE3:MODE TRIG, IN
:DIG:LINE5:MODE TRIG, IN
:TRIG:BLEN1:MODE OR
:TRIG:BLEN1:STIM1 DIG3
:TRIG:BLEN1:STIM2 DIG5
Set digital I/O lines 3 and 5 as trigger in
lines. Generate a trigger blender 1 event
when a digital I/O trigger happens on line 3
or 5.
Also see
:TRIGger:BLENder<n>:STIMulus<m> (on page 6-184)
