9: Frequently asked questions (FAQs) Model 2461 Interactive SourceMeter® Instrument
9-8 2461-901-01 A/November 2015
How do I download measurements onto the USB flash drive?
From the front panel, you can download measurements from a reading buffer to a .csv file on a USB
flash drive.
Using the front panel to save or append buffer content to a file:
1. Insert a USB flash drive into the USB port.
2. Press the MENU key.
3. Under Measure, select Reading Buffers. The MANAGE READING BUFFERS window is
displayed.
Figure 180: MANAGE READING BUFFERS window
4. Select the reading buffer that you want to save.
5. Select the Save To USB button.
6. Enter the name of the file in which to save the readings and select OK.
You only have to enter the name of the file you want to save. You do not need to enter the file
extension. All files are saved as .csv files.
7. Select Yes to confirm saving the file.
