Section

6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument

Reference Manual

6-168 2461-901-01 A/November 2015

:TRACe:SAVE

This command saves data from the specified reading buffer to a USB flash drive.

Type Affected by Where saved Default value

Command only

Not applicable

Usage

:TRACe:SAVE "<fileName>"

:TRACe:SAVE "<fileName>", "<bufferName>"

:TRACe:SAVE "<fileName>", "<bufferName>", <timeFormat>

:TRACe:SAVE "<fileName>", "<bufferName>", <timeFormat>, <start>, <end>

A string that indicates the name of the file on the USB flash drive in which to save

the reading buffer

A string that indicates the reading buffer; the default buffers (defbuffer1 or

defbuffer2) or the name of a user-defined buffer; if no buffer is specified,

defbuffer1 is used

Defines how date and time information from the buffer is saved in the file on the

USB flash drive; the values are:

• Dates, times, and fractional seconds are saved; the default value: FORMat

• Relative timestamps are saved: RELative

• Seconds and fractional seconds are saved: RAW

•

Timestamps are saved: STAMp

<start>

Defines the starting point in the buffer to start saving data

<end>

Defines the ending point in the buffer to stop saving data

Details

The filename must specify the full path (including /usb1/). If included, the file extension must be set

to .csv (if no file extension is specified, .csv is added).

For options that save more than one item of time information, each item is comma-delimited. For

example, the default format is date, time, and fractional seconds for each reading.

The Model 2461 does not check for existing files when you save. Verify that you are using a unique

name to avoid overwriting any existing .csv files on the flash drive.
