This command can be written to and read for resistance measurements. For current and voltage
measurements, it can only be read.
For current and voltage measurements, the upper limit is controlled by the current or voltage limit.
For resistance measurements, you can use this command when automatic range selection is enabled
to put an upper bound on the range that is used for resistance measurements.
The upper limit must be more than the lower limit.
If the lower limit is equal to the upper limit, automatic range setting is effectively disabled.
Example
:SENSe:RESistance:RANGe:AUTO:ULIMit 20
Set the upper limit to 20
Ω
Also see
[:SENSe[1]]:<function>:RANGe:AUTO (on page 6-62)
[:SENSe[1]]:<function>:RANGe:AUTO:LLIMit (on page 6-63)
[:SENSe[1]]:<function>:RANGe[:UPPer]
This command determines the positive full-scale measure range.
Type Affected by Where saved Default value
Instrument reset
Power cycle
Measure configuration list
Measure configuration list
Resistance: 200 MΩ
Voltage: 0.2 V
Digitize current: 100 mA
Digitize voltage: 7 V
Usage
[:SENSe[1]]:<function>:RANGe[:UPPer] <n>
[:SENSe[1]]:<function>:RANGe[:UPPer] DEFault
[:SENSe[1]]:<function>:RANGe[:UPPer] MINimum
[:SENSe[1]]:<function>:RANGe[:UPPer] MAXimum
[:SENSe[1]]:<function>:RANGe[:UPPer]?
[:SENSe[1]]:<function>:RANGe[:UPPer]? DEFault
[:SENSe[1]]:<function>:RANGe[:UPPer]? MINimum
[:SENSe[1]]:<function>:RANGe[:UPPer]? MAXimum
The measure function:
• Current: CURRent[:DC]
• Resistance: RESistance
• Voltage: VOLTage[:DC]
The digitize function:
• Digitize current: DIGitize:CURRent
• Digitize voltage:
Set this command to a specific value or a preset value:
• Current: 1 µA to 10 A
• Resistance: 2 Ω to 200 MΩ
• Voltage: 0.2 V to 100 V
• Digitize current: 1 µA to 10 A
•
Digitize voltage: 0.2 V to 100 V
