Interactive SourceMeter® Instrument Reference Manual Section 8:
2461-901-01 A/November 2015 8-273
The bit pattern that is sent when the measurement passes limit 4; range 1
The bit pattern that is sent when all limits have failed; 1 to 15; default is 15
The input line that starts the test; 5 for digital line 5, 6 for digital line 6;
The delay time before each measurement (167 ns to 10 ks); default is 0 for
no delay
The delay time after the measurement (167 ns to 10 ks); default is 0 for no
delay
The name of the reading buffer, which may be a default buffer
(defbuffer1 or defbuffer2) or a user-defined buffer; defaults to
Details
This trigger model template allows you to sort components and place them into up to four bins, based
on the comparison to limits.
To set a limit as unused, set the high value for the limit to be less than the low limit.
All limit patterns and the all fail pattern are sent on digital I/O lines 1 to 4, where 1 is the least
significant bit.
After selecting a trigger model template, you can view the trigger model blocks in a graphical format
by pressing the front-panel MENU key and under Trigger, selecting Configure. You can also add or
delete blocks and change trigger model settings from this screen. You can use the
trigger.model.getblocklist() command to view the trigger model blocks in a list format.
Also see
None
trigger.model.setblock() — trigger.BLOCK_BRANCH_ALWAYS
This function defines a trigger model block that always goes to a specific block.
Type TSP-Link accessible Affected by Where saved Default value
Function Yes
Restore configuration
Instrument reset
Configuration script Not applicable
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_BRANCH_ALWAYS, branchToBlock)
The sequence of the block in the trigger model
The block number to execute when the trigger model reaches the Always block
