Interactive SourceMeter® Instrument Reference Manual Section 3:
2461-901-01 A/November 2015 3-125
Predefined trigger models
The Model 2461 includes predefined trigger models for common applications. You can use these
predefined trigger models without changing them, or you can modify them to meet the needs of your
application.
The predefined trigger models include:
• Empty: Clears the present trigger model.
• ConfigList: Creates a trigger model that loads a source and measure configuration list. The lists
are iterated until every index in the configuration list with fewer indexes has been loaded. For
example, if the measure list has seven indexes and the source configuration list has 10, it will
iterate through seven indexes of the source list and all of the measure list. However, if the source
list has three indexes and the measure list has five, it will iterate through three indexes of
measure list and all of the indexes in the source list. At each index when the output is turned on,
a measurement is made and the output is turned off.
• LogicTrigger: Creates a trigger model that waits on an input line, delays, makes a measurement,
and sends out a trigger on the output line a specified number of times.
• SimpleLoop: Creates a trigger model that makes a specified number of readings. A count
parameter defines the number of readings.
• DurationLoop: Creates a trigger model that makes continuous measurements for a specified
amount of time. When you start this trigger model, the output is turned on.
• LoopUntilEvent: Creates a trigger model that makes continuous measurements until a specified
event occurs.
• GradeBinning: Creates a trigger model that successively measures components and compares
their readings to high or low limits to grade components.
• SortBinning: Creates a trigger model that successively measures components and compares
their readings to high or low limits to sort components.
Using a predefined trigger model
Before starting the trigger model, you need to set up your instrument for testing, including the source,
measure, and digitize settings and source and measure configuration lists.
When you load a predefined trigger model, the instrument overwrites any existing trigger models.
Using the front panel:
1. Press the MENU key.
2. Under Trigger, select Templates.
3. Next to Templates, select the trigger model template to use.
4. If the template you select has additional settings, you can use the default values or make any
necessary changes to the settings.
5. Press the TRIGGER key to initiate the trigger model. The trigger mode indicator shows the status
of the trigger mode. See Trigger mode indicator (on page 2-16) for descriptions of the indicators.
