Model 2461

Interactive SourceMeter® Instrument Reference Manual Section 6:

SCPI command reference

2461-901-01 A/November 2015 6-39

DISPlay subsystem

This subsystem contains commands that control the front-panel display.

:DISPlay:CLEar

This command clears the text from the front-panel USER swipe screen.

Type Affected by Where saved Default value

Command only

Not applicable

Usage

:DISPlay:CLEar

Example

DISP:CLE

DISP:SCR SWIPE_USER

DISP:USER1:TEXT "Batch A122"

DISP:USER2:TEXT "Test running"

Clear the USER swipe screen and switch to

display the USER swipe screen.

Set the first line to read "Batch A122" and

the second line to display "Test running".

Also see

:DISPlay:USER<n>:TEXT[:DATA] (on page 6-43)
