Model 2461

Interactive SourceMeter® Instrument Reference Manual Section 6:

SCPI command reference

2461-901-01 A/November 2015 6-177

:TRACe:TRIGger:DIGitize

This command makes readings using the active digitize function and stores them in the reading buffer.

Type Affected by Where saved Default value

Command only Not applicable Not applicable Not applicable

Usage

:TRACe:TRIGger:DIGitize

:TRACe:TRIGger:DIGitize "<bufferName>"

A string that indicates the reading buffer; the default buffers

(defbuffer1 or defbuffer2) or the name of a user-

defined buffer; if no

buffer is specified,

defbuffer1

is used

Details

A digitize function must be selected before sending this command.

This command makes the number of digitize measurements that is set by the digitize count

command.

Example

DIG:FUNC "VOLTage"

TRACe:MAKE "MyBuffer", 60000

TRACe:TRIG:DIG "MyBuffer"

TRACe:DATA? 1,5, "MyBuffer", rel

Make the digitize voltage measurement function the active

function.

Create a buffer called MyBuffer with a maximum size of

60000.

Make readings and store them in MyBuffer.

Recall the relative time when the data points were measured

for the first five readings in the buffer.

Example output:

0.000000,0.408402,0.816757,1.208823,1.617529

Also see

[:SENSe[1]]:DIGitize:COUNt (on page 6-80)

[:SENSe[1]]:DIGitize:FUNCtion[:ON] (on page 6-81)

:TRACe:MAKE (on page 6-165)
