6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument

Reference Manual

6-32 2461-901-01 A/November 2015

:CALCulate2:<function>:LIMit<Y>:STATe

This command enables or disables a limit test on the measurement from the selected measure function.

Type Affected by Where saved Default value

Command and query

Recall settings

Instrument reset

Power cycle

Measure configuration list

Save settings

Measure configuration list

0 (OFF)

Usage

:CALCulate2:<function>:LIMit<Y>:STATe <state>

:CALCulate2:<function>:LIMit<Y>:STATe?

The measure function:

• Current: CURRent[:DC]

• Resistance: RESistance

• Voltage: VOLTage[:DC]

The digitize function:

• Digitize current: DIGitize:CURRent

• Digitize voltage:

DIGitize:VOLTage

<Y>

Limit number: 1 or 2

<state>

Disable the limit test:

OFF

Enable the limit test: ON or 1

Details

This command enables or disables a limit test for the selected measurement function. When this

attribute is enabled, the limit Y testing occurs on each measurement made by the instrument. Limit Y

testing compares the measurements to the high and low limit values. If a measurement falls outside

these limits, the test fails.

If you send this command without the <function> parameter, it sets the state of math operations

for all math functions. It will not change the setting for a digitize function.

Keithley 2461 Reference Manual
