Interactive SourceMeter® Instrument Reference Manual Section 8: TSP comm
and reference
2461-901-01 A/November 2015 8-267
Example
trigger.model.load("LogicTrigger", 1, 2, 10, 0.001, defbuffer1)
Set up the template to use the digital in line and wait for a pulse from digital in line 1 to trigger measurements.
Pulse digital out line 2 when the measurement is complete.
Make 10 measurements, with a delay of 1 ms before each measurement.
Store the measurements in defbuffer1.
Also see
None
trigger.model.load() — LoopUntilEvent
This function loads a predefined trigger model configuration that makes continuous measurements until the
specified event occurs.
Type TSP-Link accessible
Affected by Where saved Default value
Function Yes
Usage
trigger.model.load("LoopUntilEvent", triggerEvent, position, clear)
trigger.model.load("LoopUntilEvent", triggerEvent, position, clear, sDelay)
trigger.model.load("LoopUntilEvent", triggerEvent, position, clear, sDelay,
bufferName)
trigger.model.load("LoopUntilEvent", triggerEvent, position, clear, sDelay,
bufferName, readingBlock
triggerEvent
The event that ends infinite triggering or readings set to occur before the
trigger; see Details
position
The number of readings to make in relation to the size of the reading
buffer; enter as a percentage (0 % to 100 %)
clear
To clear previously detected trigger events when entering the wait block
(default): trigger.CLEAR_ENTER
To immediately act on any previously detected triggers and not clear them:
trigger.CLEAR_NEVER
sDelay
The delay time before each measurement (167 ns to 10 ks); default is 0 for
no delay
bufferName
The name of the reading buffer, which may be a default buffer
(defbuffer1 or defbuffer2) or a user-defined buffer; defaults to
defbuffer1
readingBlock
Define a measure or digitize block for the trigger model; options are:
• trigger.READING_ACTIVE: Add a measure or digitize block to the
trigger model based on the active function; if no option defined,
trigger.READING_ACTIVE is used
• trigger.READING_MEASURE: Adds a measure block to the trigger
model
• trigger.READING_DIGITIZE: Adds a digitize block to the trigger
model
