Section

6: SCPI command reference Model 2461 Interactive SourceMeter® Instrument

Reference Manual

6-88 2461-901-01 A/November 2015

:SOURce[1]:CONFiguration:LIST:STORe

This command stores the active source settings into the named configuration list.

Type Affected by Where saved Default value

Command only

Recall settings

Instrument reset

Power cycle

Source configuration list

Saved settings Not applicable

Usage

:SOURce[1]:CONFiguration:LIST:STORe "<name>", <index>

<name>

A string that represents the name of a source configuration list

<index>

A number that defines a specific configuration index in the configuration list

Details

Use this command to store the active source settings to a configuration index in a configuration list. If

the index is defined, the configuration list is stored in that index. If the index is not defined, the

configuration index is appended to the end of the list. If a configuration index already exists for the

specified index, the new configuration overwrites the existing configuration index.

Refer to Instrument settings stored in a source configuration list (on page 3-35) for information about

the settings this command stores.

Example

:SOURce:CONF:LIST:CRE "biasLevel"

:SOURce:FUNC VOLT

:SOURce:VOLT:LEV 5

:SOURce:CONF:LIST:STORE "biasLevel"

Create a configuration list named biasLevel.

Set the source function to voltage and the source

voltage level to 5 V.

Store the configuration list and append it to the

end of the

biasLevel

configuration list.

Also see

:SOURce[1]:CONFiguration:LIST:CREate (on page 6-83)
