133
Changing
What the PEAK/RMS Met
er Displays
On the PEAK/RMS meter on the sidebar
, you can select and display
any two from among M
AIN 1, MAIN 2, MONITOR 1, and MONIT
OR 2.
T
o change what is displayed, tap the PEAK/RMS meter
.
132
134
