Roland M-5000 Reference Manual

190
Talkback/Oscillator
About Talkback/Talkback Return/
Oscillator
About Talkback/Talkback Return
MAIN SUBGROUP AUX MTX MIX MINUS
MAIN
SUBGROUP
AUX
MTX
MIX MINUS
PATCHBAY
INPUT
TO PATCHBAY
TO MONITOR
LEVEL
TALKBACK
TALKBACK RETURN
EXT
HPF
HPF
TALK 3 ASSIGN
TALK 2 ASSIGN
TALK 1 ASSIGN
TALKBACK
TALKBACK RETURN
Talkback is a function that sends the signal from a desired input
connector to an output bus or output patchbay. This is useful in
situations such as when the operator sends instructions to on-stage
performers, stage managers, or sta. The M-5000 has three talkback
systems, TALK 1 through 3, and each can individually be assigned to
dierent outputs and set on or o.
Talkback return is a function that sends the signal from a desired
input connector to MONITOR 1, MONITOR 2, or HEADPHONES. It is
handy at times such as when returning instructions to the operator
from another booth or location.
You make the settings for talkback and talkback return in the
TALKBACK tab of the TALKBACK/OSC window.
0“TALKBACK/OSC Window TALKBACK Tab” (p. 191)
About the Oscillator
MAIN SUBGROUP AUX MTX MIX MINUS
MAIN
SUBGROUP
AUX
MTX
MIX MINUS
SEL
PINK NOISE
WHITE NOISE
SINE WAVE
MULTISINE
TO PATCHBAY
LEVEL
OSCILLATOR 1/2
ON ASSIGN
OSC
The oscillator generates noise or a sine wave and sends it to an
output bus or output patchbay. This is useful when, for example,
measuring a venue’s acoustics or checking connections to external
equipment.
The two systems, OSCILLATOR 1 and OSCILLATOR 2, can be used at
the same time.
You use the TALKBACK/OSC window to make the settings for the
oscillator.
0“TALKBACK/OSC Window OSC Tab” (p. 192)
TALKBACK/OSC Window
To display the TALKBACK/OSC window, go to the top panel and
press the [DISP] button in the talkback section.
The following two tabs appear.
TALKBACK
Here you make settings for talkback and talkback
return.
OSC Here you make the settings for the oscillator.
