Roland M-5000 Reference Manual

Changing the Number of Input Channels/Output Buses
87
Mixer Conguration Templates
DEFAULT
Channel number Audio paths used Type
CH 1-64 64 MONO
CH 65-68 8 STEREO
MAIN 1 3 LCR
AUX 1-24 24 MONO
MTX 1-8 8
MONO
(16x8 MATRIX)
MON 1 2 STEREO
TB1 1 Talkback
OSC 1/2 2 OSC1+OSC2
HEADPHONE 2 Headphones
[TOTAL] 114
Memo
Selecting this template sets MATRIX INPUTS to 16.
ALL CLEAR
Channel number Audio paths used Type
(CH) 0
(MAIN) 0
(GRP) 0
(AUX) 0
(MINUS) 0
[TOTAL] 0
FOH
Channel number Audio paths used Type
CH 1-87 87 MONO
MAIN 1 3 LCR
GRP 1-8 8 MONO
AUX 1-16 16 MONO
MTX 1-8 8 MONO
MON 1 2 STEREO
TB1 1 Talkback
OSC 1 1 OSC1
HEADPHONE 2 Headphones
[TOTAL] 128
MONITOR
Channel number Audio paths used Type
CH 1-74 74 MONO
AUX 1-48 48 MONO
MON 1 2 STEREO
TB1 1 Talkback
OSC 1 1 OSC1
HEADPHONE 2 Headphones
[TOTAL] 128
BROADCAST
Channel number Audio paths used Type
CH 1-84 84 MONO
MAIN 1/2 8 5.1+LR
MAIN DOWNMIX 2 Downmix
AUX 1-6 6 MONO
MINUS 1-8 8 MONO
MTX 1-8 8 MONO
MON 1/2 8 5.1+LR
TB1 1 Talkback
OSC 1 1 OSC1
HEADPHONE 2 Headphones
[TOTAL] 128
THEATER
Channel number Audio paths used Type
CH 1-94 94 MONO
MAIN 1 3 LCR
AUX 1-16 16 MONO
MTX 1-8 8 MONO
MON 1 2 STEREO
TB1 1 Talkback
OSC 2 2 OSC1+OSC2
HEADPHONE 2 Headphones
[TOTAL] 128
