268

Adjusting the Detection Position of the Touch Display

If the detection position of tap operations is inaccurate depending

on the person operating the touch display or the location of the

operation, use the following method to adjust the detection

position.

1. Hold down the [MENU] and [VIEW] buttons in the top

panel’s display section and turn on the power.

The unit starts in SYSTEM CONFIG MODE.

2. Tap <TOUCH SCREEN CALIBRATION>.

3. Tap the symbols from <1> to <5>.

Tap using the location and posture of normal operation.

The unit performs correction so that the tapped location is

accurately detected.

4. When SYSTEM CONFIG MODE appears again, turn o the

power.
