Scene Memory
183
FX/GEQ/INS tab
The further tabs are displayed on the FX/GEQ/INS tab.
5 FX
5 GEQ
5 INSERT
Channel number/Channel name
Channel number Channel number
Channel name
Channel name
Tapping this turns all parameters on the row on/
o.
You set the following parameters on/o for each column.
Parameters set to “o” are excluded from scene recall.
SAFE
Sets Channel Safe on/o
FX/GEQ/INSERT for which Channel Safe is turned
on are all excluded from scene recall.
NAME INSERT name
PATCH Patchbay
PARAMETER Parameters of FX/GEQ/INSERT
Tapping the header areas of the respective columns turns the entire
column on or o.
OTHER tab
CHANNEL LINK
SETTING
Channel link setting
Interlinking Scene Memories with Other
Devices (EVENTS)
You can use the GP I/O connector, FOOT SW 1/2 jacks, and MIDI
connectors to interlink scene memories to other devices.
5 Recalling a scene on reception from the GPI connector or FOOT
SW 1 or 2 jack
5 Recalling a scene on reception from the MIDI IN connector
5 Transmission from the GPO connector on scene recall
5 Transmission from the MIDI OUT connector on scene recall
Assigning a Scene to the MIDI IN Connector
This assigns a scene to the MIDI IN connector.
1. Tap <EVENTS> for the scene you want to assign to the
connector.
The EVENTS window appears.
MIDI This displays the MIDI window.
GPI/O / FS This displays the GPI/O / FOOT SW window.
CLEAR This clears the assigned function.
CANCEL This cancels the change and closes the window.
2. Tap MIDI IN <STATUS>.
A popover for selecting MIDI data appears.
