Scene Memory
182
Recall Parameter List
To set a range to recall, using Recall parameter list.
The information displayed changes as shown below depending
on what tab has been selected at the GLOBAL SCOPE window or
RECALL PARAMETER window.
CHANNEL tab
Channel number/Channel name
Channel number Channel number
Channel name
Channel name
Tapping this turns all parameters on the row on/
o.
You set the following parameters on/o for each column.
Parameters set to “o” are excluded from scene recall.
SAFE
Sets Channel Safe on/o
Input channels for which Channel Safe is turned
on are all excluded from scene recall.
NAME Input-channel name
PATCH Input patchbay
PREAMP Preamp settings
Φ Polarity
D.GAIN Digital gain
FILTER HPF, LPF
DYN 1 Dynamics 1
DYN 2 Dynamics 2
EQ 4-band EQ
DELAY Delay
INSERT A Channel insert
INSERT B Channel insert
DIRECT OUT Direct out (on/o, send point, level)
SENDS Sends to AUX
ROUTE Sends on/o to MAIN/SUBGROUP/MIX-MINUS
PAN Pan settings
MUTE Muting
FADER Sends to MAIN
Tapping the header areas of the respective columns turns the entire
column on or o.
DCA/BUS tab
The further tabs are displayed on the DCA/BUS tab.
5 DCA
5 MAIN
5 SUBGROUP
5 AUX
5 MTX INPUT
5 MTX
5 MIX-MINUS
5 MUTE GRP
Channel number/Channel name
Channel number Channel number
Channel name
Channel name
Tapping this turns all parameters on the row on/
o.
You set the following parameters on/o for each column.
Parameters set to “o” are excluded from scene recall.
SAFE
Sets Channel Safe on/o
Output buses/DCA GROUPs/MUTE GROUPs for
which Channel Safe is turned on are all excluded
from scene recall.
NAME Outbut bus/DCA GROUP name
PATCH Output patchbay
BUS TRIM Digital gain
Φ Polarity
D.GAIN Digital gain
FILTER HPF, LPF
DYN 1 Dynamics 1
DYN 2 Dynamics 2
EQ 4-band EQ
DELAY Delay
INSERT A Channel insert
INSERT B Channel insert
SENDS Sends to AUX
ROUTE Sends on/o to MAIN/SUBGROUP/MIX-MINUS
PAN Pan settings
MUTE Muting
FADER Sends to MAIN
ASSIGN Assignments to DCA/MUTE GROUP
Tapping the header areas of the respective columns turns the entire
column on or o.
