223

Locking the Console to Prevent Operation

You can lock the console to prevent it from being operated.

Memo

If you turn o the power while the console is locked, the console

is unlocked the next time you turn on the power.

Locking the console

To lock the console, go to the MENU window and tap <LOCK

CONSOLE>.

The screen shown below is displayed while the console is locked.

Unlocking the Console

To unlock the console, tap <UNLOCK>.
