249
RS-232C
RS-232C W
indow
In the RS-232C window, y
ou set the communication speed for the
RS-232C interface.
T
o display the RS-232C window, go to the SY
STEM window and tap
<REMOTE>, then tap <RS-232C>.
R
AT
E
Selects the RS-232C communication speed from
among the following.
5
4.8k bps
5
9.6k bps
5
14.4k bps
5
31.25k bps
5
38.4k bps
5
57.6k bps
5
115.2k bps
