Roland M-5000 Reference Manual

About Eect Types
149
STEREO PHASER
Input L
Input R
Phaser L
Output L
Output R
DIR SW
Phaser R
XFB
FB
FB
DIR SW
EFF SW
EFF SW
This is a stereo-in, stereo-out phaser. It lets you apply a phaser eect
without impairing the position of the sound image that’s been set
for the stereo input, by panning or other means.
EFFECT ON Turns the eect sound on/o
DIRECT ON Turns the unprocessed sound on/o
MODE
Type of phaser
5 4STAGE
5 8STAGE
RATE Phaser rate
DEPTH Phaser depth
MANUAL
Center frequency at which the phaser eect is
applied
LFO PHASE
Phase dierence between L and R for the LFO
(Low-Frequency Oscillator)
FEEDBACK
Amount of phaser sound that is returned to the
input of the phaser
X-FEEDBACK
Amount of phaser sound that is returned to the
opposite-side input of the phaser
LEVEL Phaser level
PITCH SHIFTER x2
Input A
Pitch Shifter
Output A
DRY
Input B
Pitch Shifter
Output B
DRY
This is a dual-mono pitch shifter.
The operation procedures for A and B are the same.
MODE
MONO VOICE: Suitable for a monophonic voice.
MONO INST: Suitable for a monophonic
instrument.
POLY FAST/POLY MID/POLY SLOW: Suitable for
polyphonic instruments
PITCH Amount of pitch shift (in semitone steps)
FINE PITCH Amount of pitch shift (in one-cent steps)
WET LEVEL Level of the pitch-shifted sound
DRY LEVEL Level of the original sound
MEMO
The dierence between POLY FAST, POLY MID, and POLY SLOW
is in the length of time (delay) it takes before the pitch-shifted
sound is produced.
POLY FAST oers a shorter time until the pitch-shifted sound is
heard, but the pitch-shifted sound will be less stable.
POLY SLOW takes a longer time until the pitch-shifted sound is
heard, but the pitch-shifted sound will be more stable.
POLY MID has a response time for the pitch-shifted sound that is
between POLY FAST and POLY SLOW.
