Roland M-5000 Reference Manual

81
Changing the Number of Input Channels/Output Buses
About the Unit’s Mixing Engine
The M-5000 is provided with internal audio paths for 128 channels.
These paths can freely be used as either input channels or
output buses. You, the user, can assign these any way you like.
When considering the conguration, keep in mind that talkback,
oscillators, monitor, and other such functions also each use up one
audio paths, and plan accordingly.
You can assign the 128 audio paths to any of the following.
5 INPUT CHANNEL
5 MAIN
5 SUBGROUP
5 AUX
5 MIX-MINUS
5 MATRIX
5 Monitor
5 Talkback/Talkback return
5 Oscillator
5 Headphones
Memo
You can modify the mixer conguration without having to
restart the unit.
* You can assign output buses (MAIN, SUBGROUP, AUX, MIX-
MINUS, and MATRIX) to a total of 124 paths.
* You can create 64 output buses (SUBGROUP, AUX, MIX-MINUS,
and MATRIX) each.
Examples of Congurations Achievable Using
the Unit’s Mixing Engine
This section shows a number of mixer congurations that you can
achieve using this unit.
As you can see, this single unit can accommodate a wide range of
situations.
1 Standard
5 75 monaural input channels
5 6 stereo input channels
5 Main LR/C
5 24 AUX
5 8 MATRIX
5 Monitors, talkback, oscillator, headphones
(6 audio paths used)
2 Monitor mix
5 48 monaural input channels
5 8 stereo input channels
5 Main LR
5 54 AUX
5 Monitors 1 and 2, talkback, oscillator, headphones
(8 audio paths used)
3 FOH mix
5 79 monaural input channels
5 8 stereo input channels
5 Main LR/C
5 10 subgroups
5 6 AUX
5 8 MATRIX
5 Monitors, talkback, oscillator, headphones
(6 audio paths used)
4 Broadcast
5 72 monaural input channels
5 6 stereo input channels
5 Main 5.1 + stereo downmix (8 audio paths used)
5 8 subgroups
5 8 AUX
5 4 MIX-MINUS
5 8 MATRIX
5 Monitors 1 and 2, talkback, oscillator, headphones
(8 audio paths used)
