2.5.2 Installing
– Place lock cylinder housing cover cap -2- from above
-arrow a- on lock cylinder housing at a slight angle.
– Push lock cylinder housing cover cap -2- on door -arrow b-
until cover cap engages in lock cylinder housing.
2.6 Removing and installing lock cylinder
housing
Note
♦
A lock cylinder is now only installed on the driver door.
♦
Removal and installation is described for the right-hand lock
cylinder housing only. Apply the same instructions for the left-
hand lock cylinder housing as appropriate.
2.6.1 Removing
• Lock cylinder housing cover cap is removed ⇒ page 105
Only for lock cylinder housing with lock cylinder in driver's door
– Remove cover from securing screw -1-.
– Unscrew securing screw -1- for lock cylinder housing with lock
cylinder -2-.
For all lock cylinder housings
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
106 Rep. gr.57 - Front doors, door components, central locking
