5.2 Assembly overview - water deflector
Note
The right side is shown. The left side is similar.
1 - Water deflector
❑ Removing and installing
⇒ page 410
2 - Retaining strip
❑ Removal and installa‐
tion only with wind‐
screen removed
3 - Pop rivet
❑ Qty. 4 on A-pillar, 1 on
front wing
5.3 Removing and installing water deflector
Note
The removal and installation sequence is only for the left water
deflector. The removal and installation of the right water deflector
is similar.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
410 Rep. gr.66 - Exterior equipment
