3 Bulkhead
⇒ “3.1 Assembly overview - plenum chamber bulkhead”,
page 15
⇒ “3.2 Assembly overview - plenum chamber cover”, page 17
⇒ “3.3 Removing and installing plenum chamber cover”,
page 17
3.1 Assembly overview - plenum chamber
bulkhead
Special tools and workshop equipment required
♦ Torque wrench - V.A.G 1331-
♦ Cartridge heater - V.A.G 1939-
♦ Hand-cartridge gun - V.A.G 1628-
Materials
♦ 1-pack window adhesive
DH 009 100 03
1)
2)
♦ Activator D 181 801 A1
♦ Glass and paint primer D 009 200 02
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
3. Bulkhead 15
