2.13.2 Installing
– Align door inner seal so that vulcanised point -arrow- is at
same height as lower hinge.
– Begin installation of seal at top radius of door cut-out.
2.14 Removing and installing outer door seal
Note
♦
Removal and installation are described only for the right door
outer seal. Removal and installation of the left door outer seal
are similar.
♦
Remove backing only immediately before installation. Working
temperature approx. 20°C.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
120 Rep. gr.57 - Front doors, door components, central locking
