14 - Cover
❑ Qty. 2
15 - Rivet
❑ Qty. 3
❑ To secure bracket.
16 - Mounting bracket
❑ Attached with 3 rivets.
17 - Subframe
❑ Removing and installing ⇒ page 98
❑ Window regulator is part of assembly carrier.
❑ Window regulator motor is bolted to front of assembly carrier.
18 - Bolt
❑ Qty. 10
❑ Specified torque: 8 Nm
19 - Rivet
❑ Qty. 8
❑ To secure loudspeaker.
20 - Loudspeakers
❑ Attached with 8 rivets.
21 - Clamping brackets
❑ Qty. 2
22 - Connector
❑ On A-pillar
23 - Window regulator
❑ Part of assembly carrier
2.3 Removing and installing door window
Note
Removal and installation are described only for the right door
window. The removal and installation of the left door window is
similar.
2.3.1 Removing
Note
The bolts -3- have left-handed threads.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
344 Rep. gr.64 - Glazing
