– Move sliding headliner backwards slightly.
– Remove front bolts -arrow- on left and right. Push spring slide
forwards past the stop -1-.
– Move sliding headliner forwards and lift sliding headliner
slightly above roof aperture.
– Remove rear bolts -arrow- both sides. Push spring slide to rear
and remove sliding headliner -1- out upwards.
1.11.2 Installing
Installation is carried out in the reverse order of removal.
• Finally check function.
1.12 Removing and installing sliding/tilting
sunroof glass panel drive
1.12.1 Removing
– Removing lights and operating unit ⇒ Electrical system; Rep.
gr. 96 ; Lights and switches in roof trim; Front interior lights .
Motor change - preselection switch recognition:
Note
♦
To interrupt the authorization signal and therefore to activate
the switch recognition, the requirements described below must
be fulfilled.
♦
If this is not the case, it can lead to, that the drive does not
correctly recognise the preselection switch and does not run
to the selected positions. This can be seen if the sunroof stops
approx. 10 cm before the fully closed position when the switch
is in the closed position.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
1. Sliding/tilting sunroof with glass panel (Meritor) 185
