3.22 Removing and installing tilting mecha‐
nism and front glass panel cable
3.22.1 Removing
– Remove front glass panel ⇒ page 215 .
– Remove rear glass panel ⇒ page 219 .
– Remove assembly frame from vehicle ⇒ page 255 .
– Remove sliding roof motor ⇒ page 235 .
– Remove rear section from assembly frame ⇒ page 258 .
After removal of rear part, tilting mechanism can be slid out back‐
wards.
– Push glass panel tilting mechanism only by indicated position
-arrow b- on slider -2-, not by guide plate -1-.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
3. Panorama sliding sunroof (Arvin-Meritor) 265
